Product Catalog > Power Slide Switch
Part No. : SSW-23K32
Category :
Power Slide Switch
Circuits :
2P 3T
Timing :
non-shorting
Application :
  - Torch
Specification
Rating :
AC 125V 6A
Contact Resistance :
30m ohm
Insulation Resistance :
100M ohm at 500V DC
Withstand Voltage :
AC 1000V for 1min.
Switching Life :
10,000 cycles
Client Login
User:
Password:
Function Icon
Click add items to Inquiry Basket
Click on drawing no. to see the drawing
