Product Catalog > Side Knob Slide Switch
Part No. : SK-23D03
Category :
Side Knob Slide Switch
Circuits :
2P 3T
Timing :
shorting
Application :
  - Cassette Recorder
  - Mini-Compo
  - Radio Torch Lamp
  - Walkman
  - Caller ID
  - Cordless Telephone
  - Telephone & Answering Machine
  - Electronics Toys
Specification
Rating :
DC 30V 0.3A
Contact Resistance :
30m ohm
Insulation Resistance :
100M ohm at 500V DC
Withstand Voltage :
AC 500V for 1min.
Switching Life :
10,000 cycles
Client Login
User:
Password:
Function Icon
Click add items to Inquiry Basket
Click on drawing no. to see the drawing
