Product Catalog > Push Button Switch
Part No. : PBS-42H01F14A-K
Category :
Push Button Switch
Circuits :
4P 2T
Application :
  - Car Audio
  - Mini-Compo
Specification
Rating :
AC 125V 0.4A
Contact Resistance :
30m ohm
Insulation Resistance :
100M ohm at 500V DC
Withstand Voltage :
AC 500V for 1min.
Switching Life :
100,000 cycles
Client Login
User:
Password:
Function Icon
Click add items to Inquiry Basket
Click on drawing no. to see the drawing
