Product Catalog > Motion Switch
Part No. : MS-1301 (PATENT)
Category :
Motion Switch
Circuits :
1P 3T
Application :
  - Electronics Toys
  - Yo Yo & Spinning Top
Specification
Operating Mode :
① 1 Position 3 thows when the switch is placed as dwg.1, terminal 1 & 2 contact.when the switch is placed as dwg.2, terminal 2 & 3 contact. ② When the switch is in "OFF" position suitable vibration (left & right direction) is applied to the switch, 1 signal can be found.
③ When the switch is in "OFF" position suitable vibration (upward & downward direction) is applied to the switch, 2 signal can be found.
