Product Catalog > Pull Tab
Part No. : PT-007(Normal Close)
Category :
Pull Tab
Circuits :
1P 1T
Specification
Rating :
DC 12V 0.1A
Contact Resistance :
100m ohm max.
Insulation Resistance :
100M ohm at 250V DC
Withstand Voltage :
AC 250V for 1min.
Switching Life :
5,000 cycles
