Product Catalog > Torch Switch(Multi-Function)
Part No. : TPS-13B03
Category :
Torch Switch(Multi-Function)
Circuits :
1P 3T
Specification
Rating :
DC 9V 1A
Contact Resistance :
150m ohm
Insulation Resistance :
100M ohm at 500V DC
Withstand Voltage :
AC 500V for 1min.
Switching Life :
10,000 cycles
Client Login
User:
Password:
Function Icon
Click add items to Inquiry Basket
Click on drawing no. to see the drawing
