Product Catalog > Motion Switch
Part No. : MS-1302N (PATENT)
Category :
Motion Switch
Circuits :
1P 3T
Specification
Rating :
DC 5V 1mA
Contact Resistance :
100 ohm
Insulation Resistance :
10M ohm at 100V DC
Withstand Voltage :
AC 100V for 1min.
Switching Life :
100,000 cycles
Operating Mode :
① 1 Position 3 thows when the switch is placed as dwg.1, terminal 1 & 2 contact.when the switch is placed as dwg.2, terminal 2 & 3 contact.
② When the switch is in "OFF" position - suitable vibration (left & right direction) is applied to the switch, 1 signal can be found.
③ When the switch is in "OFF" position - suitable vibration (upward & downward direction) is applied to the switch, 2 signal can be found.
